It is known about the importance of software, and it is not new that it is everywhere. It is already part of our world for so long. As we evolve, and systems, networks, or even social interactions get more complex, the demand continuously increases, a well-known trend for all in (and not only) the field of mobile communications. Hence, as more and more data is generated, it is essential to have algorithms allowing the computation of such an amount of information, reaching results, trends, and insights that would not be possible to get without them.
Machine Learning is nowadays one of the hot topics of computation, with a wide variety of applications, greatly contributing to the technological growth in any area. Since it is inevitable to find Machine Learning in every corner of the technological world, how could these methods be involved in the mobile communication industry in an effective manner? Mobile operators and planning & optimization engineers could benefit from the automation and insights given by Machine Learning applied to mobile networks.
Machine Learning is a sub-area of artificial intelligence and computer science whose aim is to provide the machine with the capability of learning, using techniques that are similar to human behavior and the learning process. The algorithms learn from datasets and statistical models, to then perform predictions and classifications of data, which can bring useful and automated insights for a variety of applications. Machine Learning algorithms can be classified into three main types: Supervised Learning, Unsupervised Learning, and Reinforcement Learning.
From a simple inbox spam detector to anomaly detection or recommendation systems, the three types of Machine Learning are widely used nowadays on a day-to-day basis. Naturally, they differ in the way the models learn, and so the applications use the one that adapts the best to the algorithm that best fits its purpose:
Real-life examples of this type of learning are e-mail spam detection, facial recognition systems both for privacy security and surveillance systems, and predictions, such as weather or prices.
In real life, we have Unsupervised Learning in recommendation systems, such as in video streaming services and online shopping, customer segmentation (marketing), or fraud detection, such as suspicious bank transactions.
This challenging Machine Learning approach is being applied in several applications, including autonomous systems (e.g., self-driving cars or robot vacuum cleaners), healthcare, namely in dynamic treatment regimens or automated medical diagnosis, or gaming, where these models simplify the traditional way of creating video games (behaviour learning according to the game environment and goals, instead of a more fixed and complex behavioural tree).
With the development and increasing adoption of Self-Organising Networks (SON) solutions, Machine Learning is naturally on the road to evolving in the telecommunications industry and helping mobile operators giving a step forward, improving the engineering processes and the network performance. It is unquestionable the added value and benefits these solutions bring to the mobile operators, which, in the end, leads to a better end-user experience and in a better performing and resilient network.
As for Machine Learning, and considering its main types of algorithms, it is possible to list some of the use cases that could be applied to the daily life of a mobile operator, easing the work of mobile network engineers, bringing efficiencies and maximising resources:
There is a significant number of network events which can lead to service degradations, reflected in the network Key Performance Indicators (KPIs), but it is not always easy to keep a detailed track of all abnormal issues responsible for peaks of failures in a short amount of time, or other unusual degradations. Sometimes, actively identifying an issue in a single cell, over a network of thousands of cells, could be challenging, if the main KPIs are not perceptively affected. Anyway, the problem still exists, and it can impact the performance in a specific area. On the other hand, a misconfiguration of the network parameters can lead to a negative impact, affecting the user experience and, ultimately, the operator’s revenue.
The Intelligent Performance Alarmistic System model would be based on Unsupervised Learning to actively identify abnormal behaviours on the network, both in terms of statistics and configuration. The system would use the statistical and configuration data as inputs and would work with it to identify outliers. For example, if certain KPIs/counters abruptly change, or if they start having an uncommon trend, the system will create an alert for the engineers to check. Similarly, if a parameter change occurs out of the usual values, or on the most common ranges, an alert would be also given, so the engineers could confirm if that value was supposed or not.
The functionality would allow for quickly identifying network degradations at a detailed level, such as cell–level, which would traditionally be possible through continuous follow-up of all cells and KPIs, which is unpractical. Additionally, it would detect specific degradations usually not detected in the general network monitoring KPIs, given the weight of a single cell. And if several cells degrade, the system can detect them as well in a fast way. The same for the configuration part, where errors or improper configurations can be rapidly detected, minimising the impact on the network performance. As a drawback, the accuracy would need to be refined, since false alarms would need to be avoided as much as possible.
The optimisation of a mobile network is not a process where an engineer can simply follow a recipe. It depends on the issue, the causes, and several variables that can influence and change the course of troubleshooting. However, network counters help the engineers identify the causes of a KPI degradation, so then they can focus on it and reach the appropriate solution. Working as a guide, these counters are commonly used in the troubleshooting process, being one of the basics of network problem-solving, and their behaviour provides useful insights to the engineers.
The Network Troubleshooting Insight model would make use of Supervised Learning to categorise several types of network issues based on a set of attributes, i.e., a set of network performance counters. This way, the model would be trained with a dataset based on the engineer’s knowledge and experience, correlating groups of counters with causes, so it could accurately identify the main issues of the network and provide the user with the probable detailed reason for the problem. If the configuration part was added to this algorithm, a more advanced system would be created, where the settings could be crossed with statistics, so to identify possible misconfigurations.
In addition to the previous functionality, this system could also provide suggestions of possible actions to take given a particular reason. Assuming the actions performed by the engineers are registered on a platform, the model takes this data, crosses it with the network statistics (and configuration) prior to the changes, and works on it to associate problems with the solutions. This would be achieved through Unsupervised Learning.
Hence, an operator with this function would most benefit in terms of efficiency, as the engineers would save time both in the troubleshooting and optimisation, which can have an impact on the user experience, since the time for the issue resolution would decrease.
To provide the best service to the customers and have a high-performing network, mobile operators aim for certain target KPIs. As a natural process, if some of the defined KPIs are below the target, the aim is to work on the network so the KPI could fulfil its value. There could be several reasons for the KPI to be below the target, but one way of getting it on target can be through network parameter configuration. Given the nature of the network vendor’s structure, where a lot of parameters can influence several KPIs (positively or negatively), finding the best settings can be challenging sometimes. The tuning of these parameters is iterative and can involve a lot of steps, performance analysis, and changes going back and forth.
Ideally, a Configuration-based KPI Maximization model would suppress the need for manual tuning, since a set of parameters would be put to test, with the system using Reinforcement Learning to put a certain KPI (or KPIs) above a given value. As a trial-and-error procedure, the set of defined parameters would be trialled on their possible values, as well as combinations with each other, with the reward being the KPI value – the higher the value, the better. In the end, the result would be the ideal settings of the network parameters to maximise the KPI.
However, this kind of trial-and-error algorithm would not be suitable to be first put on the live network, as the system would get unsuccessful configurations before reaching an optimal solution in the iterative process, i.e., this would only be considered for the live network when the model reached a stable and accurate state. To overcome this, a possibility would be replicating the network (or part of it), on a simulator, or running the algorithm in the lab. One of the drawbacks is the lack of data to tune the model itself. Anyway, a lab environment could help in understanding what the best parameter settings would be to improve a given KPI. A similar idea was tested at AT&T labs: a Reinforcement Learning algorithm was used in a lab environment with the aim of reaching the optimal eNodeB MAC scheduler configuration, using the spectral efficiency and the gap between UE’s throughput as rewards (balancing between throughput and fairness). This study proved the effectiveness of applying this type of algorithm to improve network performance. It has several challenges, but it is surely a solution to consider for the future.
A similar idea was tested at AT&T labs: a Reinforcement Learning algorithm was used in a lab environment with the aim of reaching the optimal eNodeB MAC scheduler configuration, using the spectral efficiency and the gap between UE’s throughput as rewards (balancing between throughput and fairness). This study proved the effectiveness of applying this type of algorithm to improve network performance. It has several challenges, but it is surely a solution to consider for the future.
The network behaviour varies throughout the year, depending on the season, specific dates, or events. As time goes by and new technologies are introduced, the network profile changes as well, and the operators cannot take as granted the traffic profile from previous periods. Thus, accurate traffic predictions are of foremost importance for a mobile operator, as based on it the strategy can be drawn, and future needs and solutions can be anticipated, with great impact on the company’s operations.
Machine Learning can also bring solutions for traffic trend predictions and help the mobile operator forecast future network behaviour. For this, similarly to the methods used in weather and price predictions, the model would be based on Supervised Learning, where a regression would be used to predict future trends based on past data. As a drawback, this method might not be able to predict new trends if a completely new technology is involved, or if some abnormal event occurs, such as a pandemic, given the (lack of) accurate historical data. For instance, during a pandemic, the traffic profiles change, so those would influence the prediction of the following years if not enough data is obtained from previous years. Despite the challenges, there are Mobile Operators working on this kind of solution for traffic prediction.
The post-processing of a Drive Test usually involves the analysis of occurred events, which can point out areas of possible poor experience for the user. Drive Test processing tools can provide the engineers with a list of all the events that occurred, detailed with a set of attributes that describe the conditions during the event occurrence. With this, the engineer can have an idea of the main aspects that could have led to that event and then check in more detail in the Drive Test logs for the problem, so they can then provide a solution. In the analysis process, the events are usually associated with a cause (e.g., transmission, poor coverage, interference, capacity) and the proposals are in that scope. Handling this is sometimes time-consuming, as it involves a significant amount of data, especially if there are a lot of events.
Hence, given past data from previous analysis manually performed, it would be possible to use it as labelled data (classification), so in future analysis, the events would be categorised according to the possible cause, giving a first insight into the possible problems. For example, if an event occurred with certain attributes, such as low SINR and good RSRP, a probable reason could be interference.
This would allow the engineers to have a first insight on what would be the cause, so they could then focus on that in the analysis, saving time in the first categorisation. The model could go further and present possible optimisation actions, correlating past analysis issues and respective actions taken.
It is a fact that Machine Learning is here to stay and be a strong ally in technological development, given the increasing amount of data to process and analyse. It is proven that it is widely spread across several areas, in the most common applications of people’s daily lives, and that it can be as well widely adopted in mobile network engineering, given the range of opportunities, and the technological resources available, despite all its challenges.
Undoubtedly, Machine Learning can bring high value to Mobile Communications, as it is already observed with its involvement in SON solutions, but there is still a lot of room for improvement. Hence, the investment from the market’s key players in these models is paramount as a strategy for a future-proof solution, increasing efficiency, bringing new opportunities, and adding value to the market.
One can also ask if artificial intelligence can replace an optimisation engineer in the future; it might not replace it completely, but it can make their work better, and simplified and give room to other areas where they can focus, such as the automation itself. This highlights the importance of software awareness from the telecom engineering field since more and more automation will be part of this world.
References
[1] Chen,Y., Chen,J., Krishnamurthi,G., Yang,H., Wang,H. and Zhao,W., “Deep Reinforcement Learning for RAN Optimization and Control”, IEEE Wireless Communications and Networking Conference (WCNC), Mar. – Apr. 2021 (https://arxiv.org/pdf/2011.04607.pdf ).
[2] https://www.ibm.com/cloud/blog/supervised-vs-unsupervised-learning, Oct. 2022.
[3] https://blogs.nvidia.com/blog/2018/08/02/supervised-unsupervised-learning, Oct. 2022.
[4] https://www.v7labs.com/blog/reinforcement-learning-applications, Oct. 2022.
